Subsequent 37
廠  牌
Moog
商品價格
$53000
商品編號
211217415
商品類別
創作編曲必備
運  費
酌收 0 元 物流處理費。
( 單筆滿5000元,即享有免物流處理費優惠 )
數  量
























梁山樂客為Moog實體官方展示經銷店,享完整售後保固服務,請認明官方原廠代理經銷標章。

























Subsequent 37









Subsequent 37

The Subsequent 37® 是一款2 音符模擬合成器,建立在超強大的 Sub 37 Tribute Edition 屢獲殊榮的設計之上。 的控制面板上有 40 個旋鈕和 74 個開關,可立即根據您的創意隨意開啟大量的模擬聲音設計工具和板載排序。 每個增強功能都保留了其前身的魔力和特色,同時還提供了對聲音的新維度和改進的可玩性的訪問。


























您可以使用一系列模擬聲音設計工具









在單聲道和雙聲道演奏模式中用更廣泛的經典乾淨音色創造新的聲音











Moog 變革性的 Multidrive 電路現在遠遠超出了原始 Sub 37 的沙礫和咆哮








2 個可分配的調製總線、2 個 DAHDSR 循環包絡和一個超強大的琶音器/音序器






















SUBSEQUENT 37 混音器部分的動態餘量是 Sub 37 Tribute Edition 的兩倍。這提供了在單聲道和雙聲道演奏模式中獲得一系列新的經典乾淨音色的途徑。利用混音器新發現的靈活性,梯形濾波器中的增益級已經過重新設計,以提高諧波飽和度和模擬壓縮,從而產生整體更豐富的低端。完成 SUBSEQUENT 37 的聲音演變的是重新調整的 Multidrive 電路,它遠遠超出了原始 Sub 37 的沙礫和咆哮聲。





“我們真的很高興將社區反饋納入樂器的發展中。添加 CV 互連是起點,但我們還增加了混音器的動態餘量並顯著擴展了 Multidrive 的範圍,為後續 37 CV 提供了擴展的聲音能力和模塊化控制。”- Cyril Lance,MOOG 總工程師





除了聲音引擎增強之外,每個 SUBSEQUENT 37 還配備了一個升級的鍵床以提高可玩性,一個大功率耳機放大器足以驅動最苛刻的耳機,以及一個適用於 Windows 和 Mac 平台的軟件插件/編輯器。


























Precision Audio Analysis

In this video, Grammy Award Winner Cory Henry visits the Moog Factory to put the new Subsequent 37 through its paces, and Moog Music's Chief Engineer compares the audio output from the Sub 37 Tribute Edition and the new Subsequent 37 using an audio precision analyzer and oscilloscope.







This composition inspired by the Galilean moons of Jupiter demonstrates a range of delicate and vintage sounds within the SUB 37 Bob Moog Tribute Edition.

With the exception of processed banjo and glockenspiel (and metronome), all of the sounds have been created using a Sub 37.

















商品規格

SOUND ENGINE

Analog

POLYPHONY

Selectable Monophonic or Paraphonic (can be poly-chained)

KEYBED

37 Note Semi-weighted with After Pressure

LCD

128 X 64 pixel LCD with white backlight

CONTROLLERS

Pitch Bend, Mod Wheel, After Pressure, Velocity

SOUND SOURCES

2 Variable Waveshape Oscillators, 1 Square Wave Sub Oscillator, 1 Analog Noise Generator, 1 External Input/Filter Feedback

OSCILLATOR CALIBRATION RANGE

22Hz-6.8KHz. Note range at 8’ = 18 - 116

GLIDE MODULE

Assign to Osc1/Osc2/Both. Type - LCR, LCT, EXP, Gated, Legato







FILTER

20Hz-20KHz Moog Ladder Filter w/ 6/12/18/24 dB/Oct Filter Slopes and MultiDrive

TRANSPOSE

+/- 2 Octaves

ARPEGGIATOR/SEQUENCER

Up, Down, Order, Random, Latching, Back/Forth, Invert, +/-2 Range, Tie, Rest, MIDI Sync, 64-note sequencer

MODULATION SOURCES

LFO (Triange, Square, Saw, Ramp, Sample & Hold), Filter

EG/PM

Amp Env, Constant ON, Sine LFO, Noise LFO, Osc 1 Pitch, Osc 2 Pitch, Seq Note, Seq Vel, and Seq Mod.









MODULATION DESTINATIONS

Osc 1 Pitch, Osc 2, Osc 1 & 2 Pitch, Filter, LFO Rate, VCA Level, Osc 1 Wave, Osc 2 Wave, Osc 1 & 2 Wave, Noise Level, EG Time/PGM - Filter Resonance, Filter Drive, Filter Slope, Filter Env Amount, Filter Keyboard Amount, Osc 1 Level, Sub Osc Level, Osc 2 Level, External In/Feedback Level, Osc 1 On, Sub Osc On, Osc 2 On, Noise On, External In/Feedback On, Arp Rate, Arp Clock Division, Arp Range, Arp Back/Forth, Arp Ends, Arp Invert, Arp Gate Length, Arp Run, Glide Time, Glide OSC Choice, Glide Type, Glide Gate, Glide Legato, Glide On, LFO 1 Clock Division, LFO 1 Range, LFO 1 Sync, LFO 1 Keyboard Reset, LFO 1 Keyboard Track, Mod 1 Pitch Amount, Mod 1 Filter Amount, Mod 1 Programmable Amount, Mod 1 Programmable Destination, LFO 2 Clock Division, LFO 2 Range, LFO 2 Sync, LFO 2 Keyboard Reset, LFO 2 Keyboard Track, Mod 2 Pitch Amount, Mod 2 Filter Amount, Mod 2 Programmable Amount, Mod 2 Programmable Destination, Osc 1 Oct, Osc 2 Sync, Osc 2 Keyboard Reset, Osc 2 Oct, Osc 2 Keyboard Control, Osc 2 DUO Mode, Osc 2 Freq, Osc 2 Beat Freq, Filter Env Attack, Filter Env Decay, Filter Env Sus, Filter Env Release, Filter Env Delay, Filter Env Hold, Filter Env Vel Amount, Filter Keyboard Track, Filter Env Multitriggering, Filter Env Reset, Filter Env Sync, Filter Env Loop, Filter Env Latch, Amp Env Attack, Amp Env Decay, Amp Env Sus, Amp Env Release, Amp Env Delay, Amp Env Hold, Amp Env Vel Amount, Amp Keyboard Track, Amp Env Multitriggering, Amp Env Reset, Amp Env Sync, Amp Env Loop, Amp Env Latch, Output Volume, Bend Up, and Bend Down.

LFO PANEL FEATURES

Hi/Low Range from .01Hz–1kHz, MIDI Sync, KB Reset

ENVELOPES

DAHDSR Envelopes with Multi-Trigger, Reset, Looping, MIDI Sync, Latch, and Variable control of EG Delay, Hold, Velocity Amount, KB Tracking.

EXTERNAL AUDIO INPUT

¼” TS

AUDIO OUTPUT

¼” TS, ¼” TRS Headphones

PRESETS

256 Presets - 16 Banks x 16 presets

MIDI I/O

DIN In/Out, and MIDI over USB

CV/GATE INPUTS

Filter CV, Pitch CV, Volume CV, KB Gate

POWER

110VAC-240VAC Universal Power Supply with IEC connector

WEIGHT

22lbs

DIMENSIONS

6.75H x 26.75”W x 14.75”D

Specifications subject to change without notice.
